High Precision Digital Auto Level

Quantity:
Product Introduction

auto level measuring instruments,
Optical Auto Level
1.shunfeng 1km deviation 0.5mm with micrometer
2.top dust proof and water proof capability
3.Ultra clear lens for long range observation

Application:

This instrument is mainly suitable for high precision survey of engineering including construction project, mines, road, bridge, etc. It possesses convenient operation, clear image, water proof facility, type X air or magnetic damping and compensation mechanism, and precision of compensator. It is speedy and reliable as well.

specification
Type X2 X3 X4
Parameters
Standard deviation per kilometer double-run 1.5mm 1.5mm 1.5mm
Telescope imaging Positive image
Magnification 32X 32X 32X
Clear objective aperture 36mm 36mm 36mm
Field of view 1°20'
Shortest focusing distance 0.4m
Stadia multiplication constant 100
Stadia adding constant 0
Circular bubbke precision 8'/2mm
The division unit of dial 1°or 1gon
Working scoper for the equipment ±15'
Setting accurary ±0.3" ±0.3" ±0.3"
Screw thread connected to tripod M16 or 5/8" M16 or 5/8" M16 or 5/8"
Water proof IP4



High Precision Digital Auto Level



High Precision Digital Auto Level
